【Features】
Specification range: 146, 156,166,196
The oil-bath elastic support structure can be better adapted to the spindle’s high-speed and vibration damping performance
Spindle speed ranges from 8000 to 12000r/min
The surface is applied with advanced plasma spray-coating processing technology to improve the performance of corrosion resistance and wear resistance
【Parameter】
|
Model No.
|
Product Name
|
Bearing aperture
|
D2
|
D3
|
L
|
M
|
Applicable yarn
|
Features
|
|
BD1171
|
146 Short fiber Two- for- one twisting spindle
|
Φ8.8
|
Φ34
|
Φ140
|
65
|
M25×1.5
|
cotton yarn
|
Fine count yarn
|
|
BD1181
|
166 Short fiber Two- for- one twisting spindle
|
Φ8.8
|
Φ34
|
Φ166
|
65
|
M25×1.5
|
cotton yarn
|
Universal yarn
|
|
BD1191
|
196 Short fiber Two- for- one twisting spindle
|
Φ8.8
|
Φ45
|
Φ200
|
63
|
M25×1.5
|
cotton yarn Coarse yarn
|
|
